A wifi-enabled Power consumption relay switch. Fully compliant with New Zealand and Australian electrical standards. SDoc available.
WiFi-operated Relay Switch
Control a wide range of home appliances and office equipment (lights, power lines, security systems, heating radiators, air conditioners, etc.) from anywhere with the smallest WiFi-operated relay switch with
Shelly 1PM
- has an embedded webserver
- has been designed for installation in a limited space, such as wall mounts, electrical control panels, etc.
- can function as a standalone device, as an accessory to a home automation controller, or it may be used as another automation system's component.
- can be used for electrical circuits (up to 3.5 kW) with energy consumption monitoring, overload, and temperature protection.
| POWER | |
| Power supply AC | 110-230V ±10%, 50/60Hz |
| Power supply DC | 24 – 60V |
| SPECIAL FUNCTIONS | |
| Dry contacts | No |
| Roller shutter mode | No |
| Device temperature protection | Yes |
| Overload protection | Yes |
| Power measurement | Yes |
| Working without a neutral line | No |
| FEATURES | |
| Channels | 1 Channel |
| Maximum load | 16A |
| Operational temperature | 0°C to + 40 °C |
| Device power consumption | < 1 W |
| Intelligent On/Off | Yes |
| Local and remote control | Yes |
| Sunrise/Sunset | Yes |
| Weekly Schedule | Yes |
| UL Listed option | No |
| CONNECTIVITY | |
| Wireless/WiFi Protocol | 802.11 b/g/n |
| Radiofrequency | 2400 - 2484 MHz |
| Radio signal power | 1mW |
| Range | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
| DIMENSIONS | |
| Size | 41mm x 36mm x 17mm |
